Controllable Coupling between Flux Qubit
and Nanomechanical Resonator
by Magnetic Field
Abstract
We propose an active mechanism for coupling the quantized mode of a nanomechanical resonator to the persistent current in the loop of superconducting Josephson junction (or phase slip) flux qubit. This coupling is independently controlled by an external coupling magnetic field. The whole system forms a novel solid-state cavity QED architecture in strong coupling limit. This architecture can be used to demonstrate quantum optics phenomena and coherently manipulate the qubit for quantum information processing. The coupling mechanism is applicable for more generalized situations where the superconducting Josephson junction system is a multi-level system. We also address the practical issues concerning experimental realization.
pacs:
74.78.Fk, 85.85.+j, 03.65.LxI Introduction
In recent years, great advances in improving the coherence of superconducting qubit have made it a promising candidate for the physical realization of quantum information processing. Single qubit Rabi oscillation and Ramsey fringe have been observed and two qubits entanglement is also achieved. Meanwhile, as an artificial two-level atom, superconducting qubit is adjustable (e.g. by flux, bias voltage, etc.) and scalable. These features are favorable for quantum state engineering. A number of protocols are proposed to engineer the superconducting qubit to form a quantum network. Among them, a very intriguing and successful example is the circuit QED architecture Blais et al. (2004). By coupling the Cooper pair box (charge qubit) to the quantized field of a coplanar superconducting transmission line, a macroscopic solid-state analog of cavity QED is realized on chip. Most recently, vacuum Rabi oscillations are observed in a coupling system of 3-JJ flux qubit and LC circuit Johansson et al. (2006). Quantum optical phenomena in traditional cavity QED can be demonstrated in this solid state composite system. Furthermore, due to its special structure, it offers a number of advantages, such as strong coupling and easy controllability. Thus, some protocols that cannot be realized previously in the optical cavity QED now becomes possible Wang et al. (2004a, 2005).
The circuit QED experiments motivate us to investigate the possibility of substituting other quantum solid state devices for the transmission line. It is much desirable to couple Josephson junction qubit to a device with low energy consuming and small size. If the strong coupling and easy controllability can also be achieved, we get another favorable cavity QED structure. A possible candidate of this solid state device is the nanomechanical resonator (NAMR). Nanomechanical resonators of GHz oscillation have already been observed. It is supposed that the nanomechanical resonator enter the quantum regime at the attainable temperature of the dilution refrigerator. The schemes of coupling Josephson charge qubit or phase qubit to NAMR have already been proposed. Based on these coupling mechanisms, several quantum state engineering protocols are put forward Wilson-Rae et al. (2004); Hopkin et al. (2003); Martin et al. (2004); Zhang et al. (2005); Zhou and Mizel (2006). However, due to the difficulty to reach quantum regime of NAMR, those protocols have not been implemented experimentally yet. On the other hand, the coupling mechanism of NAMR and flux qubit is also an attractive problem since the flux qubit is supposed to have longer coherence time as it is less affected by the charge fluctuation in the structure. To our best knowledge, this has not been studied in detail previously. Here, we present a novel mechanism of coupling NAMR to flux qubit. As we present below, the coupling strength between the NAMR and the flux qubit can be adjusted conveniently by a coupling magnetic field and turned on and off within the coherence time of flux qubit. Since the coupling magnetic field is independent of the single qubit operation, it is possible to make it strong enough even for GHz oscillation. Therefore our proposal is in principle possible to approach the “strong coupling regime” of cavity QED at attainable temperature of dilution refrigerator. This coupling system acts as an analog of cavity QED system with more flexibility. We expect that it enables various applications to quantum information processing and quantum state engineering.
This paper is organized as follows: in Sec.II, we briefly review the setup of 3 Josephson-junction flux qubit and NAMR as well as their experimental progresses. Then we get into the coupling mechanism for flux qubit and NAMR. This coupling mechanism can be equally applied to rfSQUID flux qubit and phase slip flux qubit. In Sec.III, the spectrum of the coupling system is presented in the “weak coupling” and the “strong coupling” limits respectively. The readout and quantum nondemolition measurement for the flux qubit is studied in Sec.IV. We also consider the application of this coupling mechanism in quantum computation in Sec.V and generalize the coupling system to beyond spin-boson model in Sec.VI. The possible problems on experimental realization and their solutions are given in Sec. VII. In Sec.VIII, some discussions and remarks are included.
Ii coupling nanomechanical resonator and flux qubit by a transverse magnetic field
ii.1 The 3-junction flux qubit
Josephson charge qubit system has been used to couple with NAMR. Here, we study another superconducting qubit system – 3 Josephson junction (3-JJ) flux qubit Mooij et al. (1999); Orlando et al. (1999); van der Wal et al. (2000, 2003); Saito et al. (2004). In contrast with charge qubits, the flux qubit is far less sensitive to charge fluctuations. Estimations show that the flux qubit have a relatively high quality factor Orlando et al. (1999); van der Wal et al. (2003). The configuration of flux qubit consists of a superconducting loop with three Josephson junctions, and the Josephson coupling energy is much larger than the charging energy for each junction. The quantum state of this system is mainly determined by the phase degree of freedom. The Josephson energy of the three Josephson junction loop reads
(1) | |||||
where the constraint of fluxoid quantization has already been taken into account. Here, is the Josephson coupling energy of two identical junction and , are phase differences across the two junctions respectively. The Josephson energy of the third junction is , with the external flux applied in the loop and the flux quantum. In the vicinity of , if , a double-well potential is formed within each cell in the phase plane and the two lowest stable classical states have persistent circulating currents with opposite directions. Therefore, the flux qubit is also called persistent current qubit. Within the qubit subspace spanned by ( and denote clockwise and counterclockwise circulating states respectively), the Hamiltonian of the qubit system reads as
(2) |
with is the energy spacing of the two classical stable states and the tunneling splitting between the two states, and , tan. The offset of from determines the level splitting of the two states and the barrier for quantum tunneling between the states strongly depends on the value of . If the third junction is replaced by a dc SQUID, both and are tunable in experiments by the applied flux or the microwave current Mooij et al. (1999); Orlando et al. (1999).
ii.2 The nanomechanical resonator
The flexural modes of thin beams can be described by the so-called Euler-Bernoulli equations Cleland (2002). In our proposal only the fundamental flexural mode of the NAMR is taken into account. All the other modes have a much smaller coupling to flux qubit and can be neglected Armour and Blencowe (2001); Armour et al. (2002). In this case, the NAMR is modeled as a harmonic oscillator with a high-Q mode of frequency . The Hamiltonian without dissipation reads Hopkin et al. (2003); Martin et al. (2004)
(3) |
In pursuing the quantum behavior of macro scale object the nano scale mechanical resonator plays an important role. At sufficient low temperature the zero-point fluctuation of nano mechanical resonator will be comparable to its thermal Brownian motion. The detection of zero-point fluctuation of the nano mechanical resonator can give a direct test of the Heisenberg’s uncertainty principle. With a sensitivity up to 10 times the amplitude of the zero-point fluctuation, LaHaye et al. have experimentally detected the vibrations of a 20-MHz mechanical beam of tens micrometers size LaHaye et al. (2004). For a 20-MHz mechanical resonator its temperature must be cooled below 1 mK to suppress the thermal fluctuation. For a GHz mechanical resonator a temperature of 50 mK is sufficient to effectively freeze out its thermal fluctuation and let it enter quantum regime. This temperature is already attainable in the dilution refrigerator.
The lithographic technology for NAMR is rather mature. The important advantages of NAMR are the potentially higher quality factor and frequency comparable to superconducting qubit. Ever since the early demonstration of a radio frequency mechanical resonator at Caltech Cleland and Roukes (1996), great advances have been made. The attainable frequencies for the fundamental flexural modes can reach MHz for the doubly-clamped SiC mechanical resonator of the size m Roukes (2000) and GHz oscillation frequency has also been measured Huang et al. (2003). It is argued that quantized displacements of the mechanical resonator were observed despite of some opposite opinions Schwab et al. (2005). For a m beam a quality factor of has been observed at a frequency of MHz Knobel and Cleland (2003). In a carefully designed antenna shape, Gaidarzhy et al. have achieved for MHz oscillation at the temperature of mK and for GHz oscillation at the temperature of K with a comparatively large double clamped beam Gaidarzhy et al. (2005). The significantly small size (m) of the NAMR is also favorable for incorporating it in the superconducting qubit circuit.
ii.3 The composite system with tunable coupling
To achieve a “strong” interaction, the coupling dynamical variable usually should be the dominant one in the dynamics of the composite system. For the Josephson phase qubit Yu et al. (2002); Martinis et al. (2002), the phase degree of freedom dominates the dynamics and the bias current coupled with the phase is modified by the dilatational motion of the piezoelectric dilatational resonator Geller and Cleland (2005). While for the Josephson charge qubit, the coupling mechanism is that the resonator displacement modifies the effective bias charge of a Cooper-pair box Armour et al. (2002); Martin et al. (2004); Wang et al. (2004b); Zhang et al. (2005). These previous investigations enlighten us to consider the coupling between persistent current in superconducting flux qubit loop and the motion of nano mechanical resonator.
Since the Josephson coupling energy of each junction in the flux qubit is much larger than that in the charge qubit, the persistent current in the loop could be about hundreds of nano ampere van der Wal et al. (2000) in contrast with the critical current of the charge qubit (usually about nA). The magnitude of this persistent current naturally leads us to consider the magnetomotive displacement actuation and sensing technique Cleland and Roukes (1996); Cleland (2002). It is well known when a current passes through a beam with conducting material, the perpendicular arrangeed of an external magnetic field and the direction of the current generates a Lorentz force in the plane of the beam. This is just the actuation part of the magnetomotive technique. Meanwhile, the resulted displacement of the beam under the Lorentz force generates an electromotive force, or voltage, which serves as measurement. Thus, if the doubly-clamped nano beam coated with superconducting material is incorporated in the superconducting qubit loop, the persistent current induces a Lorentz force with opposite directions for clockwise and counterclockwise current. The oscillation of the NAMR is modulated by these Lorentz force. In this way, the quantized harmonic oscillation mode of the beam is coupled to the quantum state of the flux qubit system. And this is just the coupling mechanism considered in our paper.
Our proposal is illustrated in Fig.1. A 3-JJ system is fabricated on the x-y plane. The external applied magnetic flux is enclosed in the loop modulated by the control lines (the lines are not plotted). The 4-JJ version of flux qubit system can also be used here to allow the modulation of the effective Josephson energy of the third junction and hence the tunneling amplitude of the two current states. One side of the loop (indicated by thick (green) rod) is suspended from the substrate and clamped at both ends. This can be fabricated with a doubly-clamped nanomechanical beam coated with superconductor or with the superconductor itself as the mechanical resonator. A magnetic field is applied in the -direction. As we discussed above, the circulating suppercurrent under the magnetic field generates a Lorentz force in the z-direction. The magnitude of the force is , with the effective length of the resonator along -direction ( and is the actual length of the resonator, a factor depending on the oscillation mode Husain et al. (2003), for the fundamental oscillation mode of a doubly clamped beam ). This force results a forced term in the Hamiltonian, which reads . With the two-level approximation of 3-JJ loop and the singlemode boson approximation, the coupling is written as
(4) |
for . Here,
(5) |
and is the amplitude of zero point motion in z-direction of the NAMR, with the effective mass of the resonator, the frequency of the fundamental flexural mode; () is the creation (annihilation) operator of the mode of the flexural motion in z-direction. is the Pauli matrix defined in the basis of . We see that this interaction actually couples the two systems. Together with the free Hamiltonian of flux qubit and NAMR, the Hamiltonian of whole system reads
(6) |
An important advantage of this coupling mechanism is the convenient controllability. As seen from Eq.(5), the coupling constant is directly dependent on the applied coupling magnetic field . Thus, both the magnitude and sign of the coupling constant can be modified. What’s more important is that the control parameter in coupling coefficient Eq.(5) is independent from the parameters of free Hamiltonian, such as bias voltage and external magnetic flux . This means the free Hamiltonian and the interaction Hamiltonian can be manipulated independently. This full controllability is a rather favorable feature for quantum state engineering and quantum information processing protocols. It is in contrast with the coupling of charge qubit and NAMR, where the coupling strength is controlled by the bias voltage which is also the crucial parameter to determine the energy spacing of the charge qubit. For example, for bang-bang cooling of NAMR by charge qubit Zhang et al. (2005), the bias voltage should be set to certain value to induce desirable damping. Therefore the on-and-off of the interaction between the qubit and NAMR can only approximately controlled by detuning and this can result in harmful reheating of the NAMR. But in our present coupling mechanism, both the coupling coefficient and the energy spacing are independent. Thus, this “bang-bang” cooling protocol should be implemented more reliable by the flux qubit and the NAMR with above coupling mechanism.
To estimate the coupling strength, we use the following parameters in refs. Lupascu et al. (2004); Martin et al. (2004); Aldridge et al. (2001): nA, m, MHz, m, and assume the applied magnetic field to be mT. Then we have MHz. Hence we see that the “strong coupling” regime for cavity QED is potentially realizable in our scheme. This regime requires the period of the Rabi oscillation , is much shorter than both the decoherence time of the two-level system and the average lifetime of the “photon” in the “cavity” Haroche (1992). For this composite system, the decoherence time for flux qubit is s and the cavity lifetime is about s, while the Rabi oscillation time s is much shorter than the two lifetime scale. For GHz oscillation, the quality factor is rather lowGaidarzhy et al. (2005) ( GHz with ). This corresponding to a much shorter cavity lifetime (about s. However, the coupling strength can be increased by larger coupling magnetic field. For example, if we take mT, the Rabi oscillation period s which is still short enough to reach “strong coupling regime”. Therefore, this protocol might be promising in dilution refrigerator (several tens of millikelvin).
ii.4 Phase slip flux qubit and NAMR
Most recently, a new type of flux qubit – phase slip flux qubit is proposed based on coherent quantum phase slip Mooij and Harmans (2005); Mooij and Nazarov (2006). Phase slip flux qubit is formed by a high-resistance superconducting thin wire instead of the Josephson junctions. The computational basis are also the two opposed persistent current states. Our coupling scheme can be equally applicable to this type of flux qubit. There are two important advantages to consider phase slip flux qubit. First, since the superconducting thin wire can be fabricated by a suspended carbon nanotube, it acts as the phase slip center and the NAMR simultaneously. The circuit configuration is simplified (see Fig. 2). Secondly, if one use this qubit, one can free from any fluctuator due to imperfection or two-level systems hidden in the dielectric layer of Josephson junction.
Iii Energy spectrum of coupling system
The Larmor frequency of superconducting qubit is about the order of GHz, while the frequency of NAMR only reaches several hundred MHz with quality factor at present stage. Thus, the composite system of flux qubit and NAMR is in large detuning regime of cavity QED, i.e., the following condition is satisfied
(7) |
However, the superconducting flux qubit and the NAMR is non-resonant, i.e. . This is in contrast with Yale’s circuit QED experiment where the Cooper pair box is resonant with the 1D transmission line Wallraff et al. (2004). In the following, we discuss the energy spectrum of our model in two different regimes: (denoted as “weak coupling”) and (denoted as “strong coupling”). In our proposal, the two regimes can be reached by varying the applied coupling magnetic field . And the energy spectrum are qualitatively different from each other. It is notable that Ref.Serban et al. (2006) has proved that the dispersive measurement back action can be enhanced or reduced by cavity damping respectively in the two regimes.
iii.1 “Weak coupling” and sideband spectrum
For the parameters mT, MHz, both and are much smaller than . In this case, the energy spectrum can be calculated by Floquet approach or by Frölich transformation. After performing a unitary transformation on the original Hamiltonian (6), we get the effective Hamiltonian
(8) | |||||
The spectrum are plus some small off-diagonal transition terms that are of order or . As shown in Fig.3, the energy levels of the two subsystems are weakly perturbed by the coupling due to the large detuning. By applying microwave pulse to induce the transition between those levels, the blue sideband () and red sideband transition () can be observed in addition to the main zero-photon transition Goorden et al. (2004). This atomic physics phenomenon has already been observed in solid quantum system of flux qubit and dc SQUID oscillator Chiorescu et al. (2004). For our proposal, similar spectra are expected.
iii.2 “Strong coupling” and dispersive shift
With large magnetic field, for example, mT, then MHz. The magnitude of coupling is comparable to the characteristic energy scale of the NAMR. In this case, the coupling term is not a perturbation with respect to the free Hamiltonian of NAMR. Therefore, we can not use perturbation theory. However, since the large detuning condition is still hold, we resort to adiabatic elimination (or coarse-graining technique) to deal with this problem. Since , the energy spectrum of the whole system is roughly energy band structure. Then the spacing of bands is determined primarily by and the energy spacing within each band is approximately . By adiabatic eliminating the transition between different bands, we can obtain the effective Hamiltonian from eq.(6)
(9) |
where the two component Hamiltonians are
(10) |
with the frequencies
(11) |
and the new bosonic operators are defined by
(12) |
In the above equation
(13a) | |||||
(13b) | |||||
(13c) | |||||
(13d) |
Thus, for different state of the flux qubit, the energy spectrum of the NAMR is shifted by different value, or in other word, the flux qubit pulls the cavity frequency by and (see Fig.4) with
(14a) | |||||
(14b) |
In contrast with the dispersive limit discussed in circuit QED Blais et al. (2004), the dispersive shift here is asymmetric.
Iv QND measurement for flux qubit
Usually, the flux qubit is measured through a dc SQUID in the underdamped regime that is inductively coupled van der Wal et al. (2000); Saito et al. (2006) or directly coupled Chiorescu et al. (2003); Bertet et al. (2005, 2004). The external applied flux plus the flux induced by the persistent current decide the switching current of the dc SQUID. By ramping a bias current to the dc SQUID, the switching current can be recorded. When a continuous microwave is resonant with the level spacing of the two eigenstates of the flux qubit, the qubit is flipped and the switching current is changed. This results in peak and dip in the switching current level versus the applied flux. With this method, both the energy spectrum and the dynamic evolution have been observed. During this measurement process, the quantum information encoded in the qubit is destroyed Lupascu et al. (2004). It would be favorable to design a nondestructive and quantum nondemolition (QND) Braginsky and Khalili (1992) measurement protocol. A novel phase-sensitive microwave reflection approach are now applied for the readout of superconducting qubits Lupascu et al. (2004); Siddiqi et al. (2004, 2006); Lupascu et al. (2006a). The advantage of this method is that it directly probes the dynamics of the Josephson plasma resonance in both the linear and nonlinear regime without switching the detector Josephson circuit to dissipative state. It succeeded to provide very fast and far less destructive measurement of the qubit. However, the QND readout for the flux qubit Lupascu et al. (2006b) only works far away from the optimal point, where the qubit coherence is destroyed very quickly.
Here, we indicate that our composite system can be used to perform QND measurement on flux qubit. As we discussed in the previous section, in both cases, the interaction between the NAMR and the flux qubit results in the mixed energy spectrum for them. Therefore, through the spectroscopy measurement, the quantum state of one system can be detected via the spectrum of the other one. Especially, if the interaction Hamiltonian commutes with the free Hamiltonian of the measured object and does not commute with that of the measuring device, a QND measurement protocol can be implemented. This is just the case of “strong coupling” limit in our proposal. In this case, by the spectroscopy of the NAMR, the flux qubit state can be read out without perturbation. This can be predicted from Eq.(9-12): the frequency of NAMR is when the flux qubit is in the excited state, while its frequency is when the flux qubit is in the ground state. The interaction between the NAMR and the flux qubit commutes with the free Hamiltonian of the flux qubit. Hence the measured probabilities of eigenstates are not perturbed by this readout. Therefore, the spectroscopy measurement of NAMR provides a high resolution QND measurement on the qubit state. It should be noticed that this scheme does not work at the exact optimal point ( at the optimal point). However, if only the operation point is a little bit shifted away from the optimal point, e.g. , the resulting frequency shift is observable (suppose mT, MHz and , then ) in the spectrum.
This frequency shift can be measured through the frequency measurement of the NAMR. In principle, this can be done with magnetomotive technique Greywall et al. (1994); Gaidarzhy et al. (2005). During the measurement process, a perpendicular magnetic field and oscillation current is applied on the NAMR. Then, the NAMR behaves like a frequency dependent resistance. The largest effective resistance is obtained when the NAMR is resonance with the oscillation current. Thus the frequency of NAMR is inferred by the resonance peak of its voltage between its two end when we vary the frequency of the oscillation current in it. Another possible way to the frequency measurement of NAMR is to use a single-electron transistors (SET) Blencowe and Wybourne (1999); Zhang and Blencowe (2001); Schwab (2001). The SET does not require extra magnetic field which might induce unwanted perturbation to the superconducting loop. It is supposed to have very high sensitivity and is expected to reach the limit by the uncertainty principle. For this method, the mechanical motion of the NAMR couples to the SET through a lead on the NAMR that is close to the island of SET. The motion of the NAMR modulates the coupling capacitance between the lead and the SET. When there is a bias voltage on the lead of NAMR the potential of the island near the NAMR is modulated. The frequency of the mechanical motion is detected through the conductance of the SET.
On the other hand, the measurement on high-frequency mechanical oscillator has some practical difficulties as additional strong coupled transducer is required to convert its dynamics to electronic signals. There is an equally intriguing problem: to detect the property of the NAMR via the measurement of superconducting qubit since there have been some good measurement protocols of the latter. For the coupling mechanism presented in this paper, the effective Josephson energy is modified by the displacement of NAMR in a similar way as the charge energy of SET being modified by the displacement of NAMR. Thus, the flux qubit might be able to act as a transducer to detect the state of NAMR. Most recently, a QND measurement for NAMR via rfSQUID has been considered based on a configuration similar to ours Buks et al. (2006).
V Applications in quantum computation
One of the possible applications of our proposal in quantum computation is to couple two or more flux qubits together and to realize two qubit logic gate. As shown in Fig.5 (a), the NAMR serves as a quantum data bus and the two identical qubit loops are connected to it. The total Hamiltonian reads
(15) |
where and are Pauli operators for the th flux qubit. The coupling coefficient can be modulated by the magnetic field . If we fix , the parameters for manipulating single qubit (i.e., and ) operations are still tunable by adjusting and . This offers a universal architecture to realize coherent two qubit quantum logic gate Makhlin et al. (2001). Considering the inductance of the loop , we note that there is also direct magnetic coupling induced by the sharing edge , here , are the currents in the 1st and 2nd qubit loop respectively. The order of magnitude of this zz coupling is about MHz MHz. At the degeneracy point, this always-on coupling is commute with the whole Hamiltonian, therefore it is not very hard to deal with. Away from the degeneracy point, the direct magnetic coupling may have positive or negative effect with respect to concrete proposals.
More qubits can also be connected in the same way as shown in Fig.5 (b). By the tunable energy spacing of the flux qubit, we can selectively couple two qubits through the NAMR. With this configuration, we can realize the logic gate of two arbitrary flux qubits by adiabatically elimination or by dynamically cancelation of the NAMR cavity mode Raimond et al. (2001); Wang et al. (2004b).
Vi Beyond spin-boson model
In the above discussion, we have described our coupling mechanism in spin-boson regime where the 3-JJ superconducting loop is treated as a quasi two-level system, i.e., a qubit. However, when the magnetic flux is tuned away from , the lowest two energy levels cannot be isolated from other energy levels (see the energy spectrum, for example, in ref.You et al. (2005). Taking more energy levels into consideration is advantageous to investigate many intriguing phenomena that are traditionally studied in atomic physics and quantum optics. For example, with the lowest three energy levels, stimulated Raman adiabatic passage (STIRAP) can be studied and some interesting behaviors, such as electromagnetic induced transparency (EIT) and dark states, can be exhibited in the coupling system. What’s more, as the symmetry and the selection rule of the 3-level superconducting loop are different from that of the 3-level natural atom, some novel features can be demonstrated, for example, -type atom Liu et al. (2005) and persistent single photon generation Liu et al. (2006).
Our coupling protocol can also be generalized to the model of multi-level atom in cavity. In this case, the dynamics of the 3-JJ loop is not confined to the two-level subspace. With newly-defined variables , and their conjugate momentum , , the free Hamiltonian of the 3-JJ system has a similar form to that of a particle in a 2D periodical potential Orlando et al. (1999):
(16) | |||||
where and , and is the capacitance of the first and second junctions. Then the interaction Hamiltonian is still where is the current flows through the NAMR Liu et al. (2006)
(17) |
with . The current induce the transition between different eigenstates of the free Hamiltonian of 3-JJ system and numerical calculation can predict the transition amplitudes. For example, if we only consider the lowest three energy levels , and , the above Hamiltonian can be written in a three dimensional subspace:
(18) |
where is the -th eigen level of the 3-JJ system and is the corresponding eigenenergy (usually we take ). The coupling coefficient and . As shown in Fig.6, the transition amplitudes , and between the lowest three energy levels depend on . That is to say, we can control the transition between different energy levels of the uncoupled system. Apparently, this feature can be used in STIRAP technology and some other proposals based on three-level atom with the quantized field Bergmann et al. (1998). For example, when the superconducting loop is biased a little bit away from the the optimal point, a type three-level atom is formed approximately. Following the same strategy of ref.Siewert et al. (2005), replacing the lowest three energy levels of quantronium by the eigen-levels considered above, Fock-states of the NAMR can also be generated.
Vii experimental considerations
In the above discussion, we have assumed that the NAMR oscillates only in the z-direction. However, to manipulate the 3-JJ flux qubit, a bias magnetic flux is applied through the loop in the z-direction. This bias magnetic field also induces a Lorentz force on the NAMR in y-direction. Therefore there exists an always-on interaction between the flux qubit and the y-direction motion of the NAMR , where denotes the annihilation operator of the mode of the flexural motion in y-direction and the coupling strength is
(19) |
where is the zero point fluctuation of the NAMR in the y-direction. However, Since
(20) |
, with the area enclosed by the loop of 3-JJ flux qubit, this additional coupling can be substantially suppressed by a properly designed asymmetric structure of the NAMR to set . This can be made when the dimension of the NAMR in the y-direction is larger than that of the z-direction. Then the dominant coupling is the one induced by the magnetic field . The bias field for the flux qubit at is calculated as T with the loop area of Ref Majer et al. (2005) or T with a smaller loop of Ref Chiorescu et al. (2003). This corresponds a coupling strength of kHz or kHz (with ), which is always less than of the coupling induced by the external applied magnetic field even at the “weak coupling” situation discussed above. Therefore, this always-on coupling is negligible for stronger than 1 mT.
Another possible difficulty in experiments might come from the vibration of the sample (the substrate with the flux qubit and the NAMR on it). If the controlling magnetic field in the y-direction is generated by a coil located on another cold finger, then in general, there may exist uncontrollable relative motion of this sample cavity against the outside coil system. This relative oscillation between the coil and the sample induces the fluctuation of the controlling field. And more seriously, the torsional oscillation of the sample will cause the deviation of the controlling magnetic field away from y-direction, i.e., the angle between and the plane of the qubit-NAMR loop can not be zero strictly. Thus the none-zero component of in z-direction penetrating the loop causes qubit energy fluctuations and decoherence. Roughly speaking, this decoherence source is proportional to . Therefore, one need to optimize such that it is large enough to dominate the coupling but not too large to induce strong decoherence from the torsional vibration of the sample plane with respect to .
On the other hand, we could also reduce the fluctuation of the bias magnetic field of flux qubit by improving the experimental setup. For example, we could use an 8-shaped gradiometer qubit. By the modified structure of the flux (as shown in fig.7), we can cancel the uniform magnetic field fluctuations over the qubit in the z-direction. The magnetic field threading the loop of the flux qubit is measured by the readout SQUID. Then with suitable feedback to compensate the fluctuation mentioned above, the bias magnetic field in the qubit-NAMR loop can be stabilized. In this case, strong magnetic field is attainable by the off-chip coil. However, scaling up to many qubits is not so straightforward and needs further consideration.
Another possible solution to overcome the above obstacles is to prepare by a superconducting coil and fix it on the sample chip at the dilution temperature. This method has advantageous that the setup of the proposed controllable coupling mechanism need not be modified and sufficient strong controlling magnetic field can be achieved.
Viii Discussions and remarks
In summary, we propose a novel solid-state cavity QED architecture that can reach the “strong coupling regime” based on a superconducting flux qubit and an NAMR. In this composite system, the quantized flexural mode of the NAMR is coupled with the persistent current generated in the superconducting loop. The coupling strength can be independently modulated by an external magnetic field. We study the entangled energy spectrum of this composite system and find that a QND measurement of flux qubit can be made in the dispersive limit. This composite system can be scaled up and the coupling mechanism can be extended to the case that the superconducting junction is a multi-level system. We also carefully examine the practical issues for experimental realization. The controllable strong coupling and the scalability enable coherent control over this system for the quantum information processing as well as quantum state engineering. Besides, this cavity QED architecture offers a new scenario to demonstrate the intriguing phenomena of quantum optics in solid-state quantum device. It also provides a possibility to test the quantization effect of mechanical motion.
Acknowledgements.
This work is supported by the NSFC with grant Nos. 90203018, 10474104, 60433050 and 10574133. It is also funded by the National Fundamental Research Program of China with Nos. 2001CB309310 and 2005CB724508. Y.D. Wang thank J. Q. You and P. Zhang for helpful discussions. This work is also partly supported by the JSPS-KAKENHI with grant Nos. 16206003 and 18201018. K. S. thanks J. Plantenberg, C. J. P. M. Harmans, and J. E. Mooij for helpful discussions.References
